Information
Since fingerprint & card access users doesn’t use mobile apps to unlock the door, therefore the uploading of unlock data will be delayed until the next mobile apps unlock occurs. Only then the unlock data records will be uploaded to the cloud. Due to the timeliness cannot be assured, the smart gateway is required for those wanting to check the unlock records from time to time.
Our Smart Gateway processes and transfers the data through Bluetooth and Wi-Fi dual signal. In this way, the lock does not need to connect to the internet but allows the user to retrieve real-time records.
Specifications
Dimensions
Size ï¼·60mm x H138mm x T12mm
Weight 0.2KG
Material
Body Plastic
Communication Method
- Bluetooth 4.1 BLE
- WiFi
Smartphone Ready
Requires iOS (9.0 or higher) or Android (5.0 or higher) smartphones.
Batteries & Voltage
Power supply Direct current
Stand-by current ≈35μA
Operating current ≈200 mA
